800MHz高速數據采集及回放系統
產品簡介： 4路，800MHz高速數據采集及回放系統，可存儲到8TB硬盤。
售價：￥0
緊湊的數據記錄儀（流存儲）
持續的記錄和回放在800兆字節/秒
獨立操作通過以太網或主機系統命令/控制
1U的底盤20英寸高，17英寸寬
可擴展的數據存儲容量8TB
固態硬盤驅動器
前面板顯示狀態顯示
8通道的電纜接口
多源數據記錄能力
最多4個外部輸入通道
多個外部接口可包括系列FPDP，技術，seriallite二，10gige
100-240vac內部電源供應器
The Big River? LTX3 recording system provides up to 800 MB/s recording and playback performance in a compact, power efficient package. At 17” in width and 20” in depth and 1.75” tall, the LTX3 provides a new level of exceptional performance and capacity for mobile, portable or space constrained recording and playback applications.
The system can operate independently from a host computer with command/control performed over a network connection. Control can also be automated from a software application using the StreamStor? software API from a network connected computer. Cabled PCIe provides connectivity to a host computer for command/control and/or data access.
When configured with Solid State Drives, the system provides a robust platform with shock and vibration tolerance. The drive shelf is isolated from the chassis and unique wedge locks secure each drive.
The Front panel status display provides key operational parameters including drive status, temperature conditions and possible error conditions.
Based on the StreamStor? Amazon Express architecture, the LTX3 supports all of the same external interface mezzanine cards as the Amazon Express platform. This includes Serial FPDP, LVDS and 10GigE.
- Compact data recorder based on StreamStor? Amazon Express
- Sustained recording and playback at up to 800 MB/s
- Standalone operation via Ethernet or host system command/control
- 1U chassis - 20” deep, 17” wide
- Scalable data storage capacities to 8 TB
- Solid-state or hard drive (notebook) media
- Front Panel OLED Status Display
- 8 lane Cabled PCIe interface
- Multi-source PCI Express recording Capability
- Up to 4 external input channels
- Multiple external interfaces available including Serial FPDP, LVDS, SerialLite II, 10GigE
- 100-240VAC internal power supply
